Stainless Steel Sanitary Valves - Non-Resort Ball Valve

Specification

Sanitary non-resort ball valve is used in situations where tight shut off is necessary. Providing superior ease of operation, these ball valves can maintain and regulate high volume, high pressure and high temperature flow. They offer rugged construction, providing for a long service life and comparably low cost. We can provide sanitary ball valves in stainless steel 304 or 316L with different connection end. A customized end will also be available if a drawing is offered.

Sanitary non-retention ball valve is a two splitted design sanitary ball valve, the combination is connected by heavy clamp. Non-retention ball valve is made in stainless steel 1.4301, 1.4404 or T316L, T304 ete of DIN, SMS standards etc., it is without dead angle, and no retention of flow. Wellgreen sanitary provides a wide range of sanitary valves for food processing, beverages, fruit juices, wine, biopharmaceutical etc.

Strength:

1. Stainless steel T316L, T304, 1.4301, 1.4404 or specified.
2. Valve body combined with clamp connection.
3. Valve body is renewable and changed to other connections.
4. Small operated torque.
5. Easily disassemble without special tools.
6. Gasket materials complies with FDA 177.2600.
7. Connected end of tri-clamp,weld,thread available.
8. Standard of DIN, SMS, ISO, IDF, BPE, RJT etc.

Application:

Food, Brewery, Beverage, Dairy, Pharmaceutical, Biopharm etc.

<table border="1" cellpadding="0" cellspacing="0" "="">

PRODUCT Sanitary Non-Retention Ball Valve DIMENSION DN10 ~ DN65 MATERIAL T304, T316L, EN 1.4301, EN 1.4404 etc. STANDARD DIN,SMS,ISO,IDF,BPE,RJT etc. SEALING GASKET Silicone, EPDM, PTFE, Buna-N etc. TEMPERATURE -30°C / -22°F up to +120°C/ +248°F APPLICATION Pharmacy, Beer, Food, Petroleum, Dairy, Beverage,Biotech ,Cosmetics etc. How to order *Part Name*Size *Material *Quantity *Standard

For more information, please contact us.
