ASTM A269 / A213 Seamless Stainless Steel Pipe , Cold Drawing & Cold Rolling Pipes

Ask Lasest Price
Brand Name :	KAYSUNS
Model Number :	KS-SMLS
Certification :	PED,ISO
Price :	USD
Supply Ability :	500Tons per Month
Delivery Time :	30-45days

Add to Cart

Product Details
Company Profile

ASTM A269 / A213 Seamless Stainless Steel Pipe , Cold Drawing & Cold Rolling Pipes

ASTM A269 / A213 Seamless Stainless Steel Pipe , Cold Drawing & Cold Rolling Pipes

Cold rolling is a preferred production process for high precision seamless stainless steel tube. Most of our heat exchanger tubes and precision tubes are cold rolled tubing. This technique provides a high forming rate, narrow tolerances and good turnouts. At present, the largest diameter we can get is 114.3mm for this processing.
Cold drawing is the common process for our ss tubings and pipes. Cold drawn stainless steel pipe will get a very narrow tolerance ranges, and keep the chemical element in a good condition. Additionally, the cold drawing process is the perfect choice for situations which place high requirements on the quality of the surface structure.

Application	For fluid & gas transport
Application	Structure & machining etc
Advantages	Advanced technology of cold draw machine
	Advanced annealing machine
	Better mechanical property
	More precise dimension
	Perfect inspection method and inspection equipment etc

Size:	1/2” to 60” (DN15 ~DN1500), outer diameter up to 1500mm
Rate:	SCH5S to SCHXXS
Standard:	ASTM A312, A213, A268,A269, A249, A270, A376,A511; ASTM A789, A790; ASTM B163, B165, B167, B407, B423, B444, B622, B677, B729; EN10216-5, EN/DIN17455,EN/DIN17456, EN/DIN17458DIN2462 etc.
Material:	Stainless: TP304,304L,304H,316,316L,316H,316Ti,317,317L,309S,310S,310H,347,347H,321,321H, 904L, S31254 (mat.1.4301,1.4307,1.4948,1.4401,1.4404,1.4571,1.4438,1.4438, 1.4833,1.4841,1.4845,1.4845,1.4450,1.4541,1.4878,1.4539, 1.4547/254SMO) etc. Duplex: UNS S31803 , S32205, S32750,S32760,S32304 (Mat.1.4462,1.4410,1.4501,1.4362)etc. Alloy: Monel 400, Inconel 600, Inconel 625, Incoloy 800, Incoloy 800H, Incoloy 825, Hastelloy B2, Hastelloy C-22, Hastelloy C-276, 15-5PH, 17-7PH,Cu70Ni30(C71500/B30), Cu90Ni10(C70600/B10)etc.

Chemical Composition

	C(max)	Si(max)	Mn(max)	P(max)	S(max)	Cr	Ni	Mo	Ti
TP304/1.4301	0.080	1.00	2.00	0.045	0.030	18.0-20.0	8.0-10.5
TP304L/1.4307	0.035	1.00	2.00	0.045	0.030	18.0-20.0	8.0-12.0
TP304H/1.4948	0.04-0.10	1.00	2.00	0.045	0.030	18.0-20.0	8.0-12.0
TP316/1.4401	0.080	1.00	2.00	0.045	0.030	16.0-18.0	11.0-14.0	2.0-3.0
TP316L/1.4404	0.035	1.00	2.00	0.045	0.030	16.0-18.0	10.0-14.0	2.0-3.0
TP316Ti/1.4571	0.080	1.00	2.00	0.045	0.030	16.0-18.0	10.0-14.0	2.0-3.0	0.7>5x(C+N)
TP321/1.4541	0.080	1.00	2.00	0.045	0.030	17.0-19.0	9.0-12.0		0.7>5x(C+N)
TP317L/1.4449	0.080	1.00	2.00	0.045	0.030	18.0-20.0	11.0-14.0	3.0-4.0
TP347H/1.4912	0.04-0.10	1.00	2.00	0.045	0.030	17.0-19.0	9.0-13.0
TP309S/1.4833	0.080	1.00	2.00	0.045	0.030	22.0-24.0	12.0-15.0	0.75
TP310S/1.4845	0.080	1.00	2.00	0.045	0.030	24.0-26.0	19.0-22.0	0.75

ASTM A269 A213 Seamless Stainless Steel Pipe , Cold Drawning & Cold Rolling Pipes

Our factory is a leading manufacturer and supplier for qualified stainless steel seamless pipes, includes ASME/ASTM, EN/DIN, JIS series stainless steel pipes, and a wide range for material grades.

For more information, please contact us.
